Num

Parametric Name

Detailed Description

1

Main chip

CC1101, from Norway

2

Module size

15* 28mm

3

Interface

2*4*2.54mm, you can use the universal plate and DuPont line

4

Supply voltage

1.9-3.6V DC

5

Communication voltage

0.7VDD-5.2VDC, VDD is the supply voltage of module

6

Measured distance

410m@250K

7

Maximum power

10dbm

8

Air Rate

1.2K-500K. Due to the physical properties of the band 433M, Recommended no more than 20Kbps

9

Shutdown Current

About 0.6uA.

10

Power Level

Multi-adjustable

11

Transmitting current

About 29.2mA@433MHz

12

Receiving current

About 16mA

13

Antenna

Spring antenna

14

Communication Interface

Standard SPI Mode 0, the maximum rate is 10Mbps

15

Transmitting length

Single data packet is 1-64 bytes

16

Receiving length

Single data packet is 1-64 bytes

17

RSSI Support

Support

18

Reception sensitivity

-117dbm@1.2Kbps

19

Work temperature

-30 - +85℃

20

Work humidity

Relative humidity :10% - 90%

21

Storage temperature

-40 - +125℃

22

Working frequency

387MHz – 464MHZ
